Product overview：
AC504GE is a full Gigabit high-performance smart WiFi certified gateway with three-in-one functions of AC, gateway, and POE power supply. It can realize unified configuration and management of wireless APs and meet the export gateway needs of small and medium-sized enterprises. It is an ideal choice for hotel chains and enterprises. , wireless network solutions for schools, shopping malls, restaurants, etc. It has the best layout and simple configuration; at the same time, this product also supports intelligent flow control function, intelligently selects priorities according to application types, easily solving the problem of various P2P programs occupying network bandwidth, and has high performance, high reliability, and ease of use. The features of easy installation and maintenance greatly save material and labor costs in network layout.
Product features：
|
Hardware specifications |
|
|
Model |
AC504GE |
|
CPU |
MTK MT7621 |
|
Flash |
16MB |
|
Memory |
256MB |
|
Maximum number of managed AP's supported |
64 |
|
Recommended maximum number of users |
100 |
|
Interface |
1×10 / 100 / 1000M Adaptive Ethernet WAN port 4×10 / 100 / 1000M Adaptive Ethernet LAN ports 1 reset bond 1 DC 12V 0.5A Support POE power supply: maximum 30W Support a variety of authentication methods Support PPPoE |
|
Reset |
reset（Press and hold for 10 seconds to restore factory default configuration ） |
|
Status light |
WAN port lamp, LAN port lamp, |
|
Operating power |
﹤65W |
|
Dimension (L*W*H) |
114mm * 82.5 mm * 25mm |
|
Net/Gross Weight |
<0.13kg / <0.45kg |
|
Work environment |
Working temperature: -40°C～65°C Storage temperature: -40°C～70°C Humidity: 5% ~ 95% (no condensation)
|
